品質に関わる全ての数字を管理することで、
今後の改善に役立てます。
品質管理&保証部 |
---|
材料入荷&品質管理抜き取り検査(AQL基準). |
製造工程&保証システムオンラインQC(清潔、印刷、チップ位置確認). |
出荷検査&品質管理機能検査(電気、AC/DC、端子ピン、機構). |
LCDモジュール(一般製品) | ||||
---|---|---|---|---|
No | 試験項目 | Test Condition | 判定基準 | |
1 | 高温放置試験 | Storage at 80±2°C 240 hrs | MIL-202E | |
2 | 低温放置試験 | Storage at-30±2°C 240 hrs | MIL-202E | |
3 | 高温高湿放置試験 | 1. Storage 240 hrs 60°C, 90~95%RH (Polarizer may fail in this environment) Or 2. Storage 96~100hrs 40±2°C,90~95%RH |
MIL-202E | |
4 | 温度サイクル試験 |
-20°C → 25°C → 70°C → 25°C |
MIL-202E | |
5 | 振動試験(包裝) | 10~55Hz(1 Minute)1.5mm direction each time by X,Y And Z Direction x (Each 2hrs) | MIL-202E | |
6 | 落下試験(包裝) | Packing Weight (kg) | Drop High (cm) | MIL-810E |
0 ~ 45.4 | 122 | |||
45.4 ~ 90.8 | 76 | |||
90.8 ~ 454 | 61 | |||
Over 454 | 46 | |||
7 | 静電気試験 | Air Discharge: Apply 2KV with 5 times discharge for each polarity +/-. |
Contact Discharge: Apply 250V with 5 times discharge for each polarity +/-. |
IEC 61000-4-2 |
Testing location: |
Testing location: 1. Apply to bezel. 2. Apply to Vdd, Vss. |
◎Result Evaluation Criteria :
Under the display quality test conditions with normal operation state. Do not change these
conditions as such changes may affect practical display function.
(Normal operation state)
Temperature:+20~30°C
Humidity:50~70%
Atmospheric pressure:86~106Kpa
◎Please refer to the product specification for the exact reliability conditions.
項目 | 顧客 | 営業 | R&D | 品質 保証 | 製 造 | 生産管理 | 資材 | 在庫チェック | |||
---|---|---|---|---|---|---|---|---|---|---|---|
マーケティング &デザイン |
|||||||||||
サンプル承認 | |||||||||||
試作&量産 | |||||||||||
出荷 | |||||||||||
営業フォロー | |||||||||||
品質保証 |
|
